? Compatible with 18650 and 21700, modularized design, easy to changeover
? Whole tray/ flying probe test
? Unique wiring anti-interference design
? Automatic calculation of K value and equipped with MES interface
? Fully automatic calibration tooling, ensuring test accuracy of voltage and internal resistance
Items | Parameters |
First Time Yield | 99.9% |
Positioning Accuracy | 0.5mm |
Equipment Capacity | ≥300PPM |
Voltage Testing Accuracy | a)Voltage range: DC 0~10000mV b)Test accuracy: ±0.0020%rdg. ±12μm c)Cylindrical cell voltage testing accuracy:± 0.1mV |
Internal Resistance Testing Precision | a)Range of internal resistance: 0μΩ~3KΩ b)Testing accuracy: ±(0.5%rdg.+10dgt.) c)Testing frequency: 1KHz±0.2Hz d)Testing accuracy: ± 0.1mΩ |
