? Fully automatic loading and unloading; Odd-even segment test
? Wide compatibility range, modularized design, easy to changeover
? Self-designed Probe, long lifetime, easy to maintenance
? Calibrating the current and voltage with power calibration tooling.
Items | Parameters |
Single Machine Capacity | ≥16PPM |
System Specification | 20A\60A\120A\250A\450A\650A\ customizable |
Discharge Voltage Setting Range | 1500-5000 mV |
Current /Voltage Testing Accuracy | ±0.05%FS |
Range of Voltage Measurement | 0-5000 mV |
Current Setting Range | (0.1%-100%) of FS |
Time of Discharge Measurement | Designed according to customer demands |
Sampling Frequency | 1KHZ |
