? Fully automatic loading and unloading; Odd-even segment test
? Self-designed fixture, long lifetime, full automatic, easy for maintenance
? Wide compatibility range, modularized design, flexible design, easy to changeover
? Calibrating the current and voltage with power calibration tooling
Items | Parameters |
Single Machine Capacity | ≥16PPM |
System Spec. | 20A\60A\120A\200A\250A\450A\650A customizable |
Discharging Voltage Setting Range | 1500-5000 mV |
Current/Voltage Testing Accuracy | ±0.05%FS |
Voltage Testing Range | 0~5000 mV |
Current Setting Range | (0.1%~100%) FS |
Discharging Measurement Time | Design according to customer needs |
Sampling Frequency | 1KHZ |
